GitLens is highly customizable and provides many configuration settings to allow the personalization of almost all features.

Current Line Blame Settings

Name	Description
`gitlens.currentLine.dateFormat`	Specifies how to format absolute dates (e.g. using the `${date}` token) for the current line blame annotations. See the Moment.js docs for valid formats
`gitlens.currentLine.enabled`	Specifies whether to provide a blame annotation for the current line, by default. Use the Toggle Line Blame Annotations command (`gitlens.toggleLineBlame`) to toggle the annotations on and off for the current window
`gitlens.currentLine.format`	Specifies the format of the current line blame annotation. See Commit Tokens in the GitLens docs. Date formatting is controlled by the `gitlens.currentLine.dateFormat` setting
`gitlens.currentLine.pullRequests.enabled`	Specifies whether to provide information about the Pull Request (if any) that introduced the commit in the current line blame annotation. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.currentLine.scrollable`	Specifies whether the current line blame annotation can be scrolled into view when it is outside the viewport. NOTE: Setting this to `false` will inhibit the hovers from showing over the annotation; Set `gitlens.hovers.currentLine.over` to `line` to enable the hovers to show anywhere over the line.

Git CodeLens Settings

Name	Description
`gitlens.codeLens.authors.command`	Specifies the command to be executed when an authors CodeLens is clicked, set to (`gitlens.toggleFileBlame`) by default. Can be set to `false` to disable click actions on the CodeLens. `gitlens.toggleFileBlame` – toggles file blame annotations `gitlens.toggleFileHeatmap` – toggles file heatmap `gitlens.toggleFileChanges` – toggles file changes since before the commit `gitlens.toggleFileChangesOnly` – toggles file changes from the commit `gitlens.diffWithPrevious` – opens changes with the previous revision `gitlens.revealCommitInView` – reveals the commit in the Side Bar `gitlens.showCommitsInView` – searches for commits within the range `gitlens.showQuickCommitDetails` – shows details of the commit `gitlens.showQuickCommitFileDetails` – show file details of the commit `gitlens.showQuickFileHistory` – shows the current file history `gitlens.showQuickRepoHistory` – shows the current branch history `gitlens.openCommitOnRemote` – opens the commit on the remote service (when available) `gitlens.copyRemoteCommitUrl` – copies the remote commit url to the clipboard (when available) `gitlens.openFileOnRemote` – opens the file revision on the remote service (when available) `gitlens.copyRemoteFileUrl` – copies the remote file url to the clipboard (when available)
`gitlens.codeLens.authors.enabled`	Specifies whether to provide an authors CodeLens, showing number of authors of the file or code block and the most prominent author (if there is more than one)
`gitlens.codeLens.enabled`	Specifies whether to provide any Git CodeLens, by default. Use the Toggle Git CodeLens command (`gitlens.toggleCodeLens`) to toggle the Git CodeLens on and off for the current window
`gitlens.codeLens.includeSingleLineSymbols`	Specifies whether to provide any Git CodeLens on symbols that span only a single line
`gitlens.codeLens.recentChange.command`	Specifies the command to be executed when a recent change CodeLens is clicked, set to (`gitlens.showQuickCommitFileDetails`) by default. Can be set to `false` to disable click actions on the CodeLens. `gitlens.toggleFileBlame` – toggles file blame annotations `gitlens.toggleFileHeatmap` – toggles file heatmap `gitlens.toggleFileChanges` – toggles file changes since before the commit `gitlens.toggleFileChangesOnly` – toggles file changes from the commit `gitlens.diffWithPrevious` – opens changes with the previous revision `gitlens.revealCommitInView` – reveals the commit in the Side Bar `gitlens.showCommitsInView` – searches for commits within the range `gitlens.showQuickCommitDetails` – shows details of the commit `gitlens.showQuickCommitFileDetails` – show file details of the commit `gitlens.showQuickFileHistory` – shows the current file history `gitlens.showQuickRepoHistory` – shows the current branch history `gitlens.openCommitOnRemote` – opens the commit on the remote service (when available) `gitlens.copyRemoteCommitUrl` – copies the remote commit url to the clipboard (when available) `gitlens.openFileOnRemote` – opens the file revision on the remote service (when available) `gitlens.copyRemoteFileUrl` – copies the remote file url to the clipboard (when available)
`gitlens.codeLens.recentChange.enabled`	Specifies whether to provide a recent change CodeLens, showing the author and date of the most recent commit for the file or code block
`gitlens.codeLens.scopes`	Specifies where Git CodeLens will be shown in the document `document` – adds CodeLens at the top of the document `containers` – adds CodeLens at the start of container-like symbols (modules, classes, interfaces, etc) `blocks` – adds CodeLens at the start of block-like symbols (functions, methods, etc) lines
`gitlens.codeLens.symbolScopes`	Specifies a set of document symbols where Git CodeLens will or will not be shown in the document. Prefix with `!` to avoid providing a Git CodeLens for the symbol. Must be a member of `SymbolKind`

Status Bar Settings

Name	Description
`gitlens.statusBar.alignment`	Specifies the blame alignment in the status bar `left` – aligns to the left `right` – aligns to the right
`gitlens.statusBar.command`	Specifies the command to be executed when the blame status bar item is clicked `gitlens.toggleFileBlame` – toggles file blame annotations `gitlens.toggleFileHeatmap` – toggles file heatmap `gitlens.toggleFileChanges` – toggles file changes since before the commit `gitlens.toggleFileChangesOnly` – toggles file changes from the commit `gitlens.diffWithPrevious` – opens changes with the previous revision `gitlens.revealCommitInView` – reveals the commit in the Side Bar `gitlens.showCommitsInView` – searches for commits within the range `gitlens.showQuickCommitDetails` – shows details of the commit `gitlens.showQuickCommitFileDetails` – show file details of the commit `gitlens.showQuickFileHistory` – shows the current file history `gitlens.showQuickRepoHistory` – shows the current branch history `gitlens.openCommitOnRemote` – opens the commit on the remote service (when available) `gitlens.copyRemoteCommitUrl` – copies the remote commit url to the clipboard (when available) `gitlens.openFileOnRemote` – opens the file revision on the remote service (when available) `gitlens.copyRemoteFileUrl` – copies the remote file url to the clipboard (when available)
`gitlens.statusBar.dateFormat`	Specifies how to format absolute dates (e.g. using the `${date}` token) in the blame information in the status bar. See the Moment.js docs for valid formats
`gitlens.statusBar.enabled`	Specifies whether to provide blame information in the status bar
`gitlens.statusBar.format`	Specifies the format of the blame information in the status bar. See Commit Tokens in the GitLens docs. Date formatting is controlled by the `gitlens.statusBar.dateFormat` setting
`gitlens.statusBar.pullRequests.enabled`	Specifies whether to provide information about the Pull Request (if any) that introduced the commit in the status bar. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.statusBar.reduceFlicker`	Specifies whether to avoid clearing the previous blame information when changing lines to reduce status bar “flashing”
`gitlens.statusBar.tooltipFormat`	Specifies the format (in markdown) of hover shown over the blame information in the status bar. See Commit Tokens in the GitLens docs

Hover Settings

Name	Description
`gitlens.hovers.annotations.changes`	Specifies whether to provide a changes (diff) hover for all lines when showing blame annotations
`gitlens.hovers.annotations.details`	Specifies whether to provide a commit details hover for all lines when showing blame annotations
`gitlens.hovers.annotations.enabled`	Specifies whether to provide any hovers when showing blame annotations
`gitlens.hovers.annotations.over`	Specifies when to trigger hovers when showing blame annotations `annotation` – only shown when hovering over the line annotation `line` – shown when hovering anywhere over the line
`gitlens.hovers.avatars`	Specifies whether to show avatar images in hovers
`gitlens.hovers.avatarSize`	Specifies the size of the avatar images in hovers
`gitlens.hovers.changesDiff`	Specifies whether to show just the changes to the line or the set of related changes in the changes (diff) hover `line` – Shows only the changes to the line `hunk` – Shows the set of related changes
`gitlens.hovers.currentLine.changes`	Specifies whether to provide a changes (diff) hover for the current line
`gitlens.hovers.currentLine.details`	Specifies whether to provide a commit details hover for the current line
`gitlens.hovers.currentLine.enabled`	Specifies whether to provide any hovers for the current line
`gitlens.hovers.currentLine.over`	Specifies when to trigger hovers for the current line `annotation` – only shown when hovering over the line annotation `line` – shown when hovering anywhere over the line
`gitlens.hovers.detailsMarkdownFormat`	Specifies the format (in markdown) of the commit details hover. See Commit Tokens in the GitLens docs
`gitlens.hovers.enabled`	Specifies whether to provide any hovers
`gitlens.hovers.autolinks.enabled`	Specifies whether to automatically link external resources in commit messages
`gitlens.hovers.autolinks.enhanced`	Specifies whether to lookup additional details about automatically link external resources in commit messages. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.hovers.pullRequests.enabled`	Specifies whether to provide information about the Pull Request (if any) that introduced the commit in the hovers. Requires a connection to a supported remote service (e.g. GitHub)

View Settings

Name	Description
`gitlens.views.defaultItemLimit`	Specifies the default number of items to show in a view list. Use 0 to specify no limit
`gitlens.views.formats.commits.label`	Specifies the format of commits in the views. See Commit Tokens in the GitLens docs
`gitlens.views.formats.commits.description`	Specifies the description format of commits in the views. See Commit Tokens in the GitLens docs
`gitlens.views.formats.files.label`	Specifies the format of a file in the views. See File Tokens in the GitLens docs
`gitlens.views.formats.files.description`	Specifies the description format of a file in the views. See File Tokens in the GitLens docs
`gitlens.views.formats.stashes.label`	Specifies the format of stashes in the views. See Commit Tokens in the GitLens docs
`gitlens.views.formats.stashes.description`	Specifies the description format of stashes in the views. See Commit Tokens in the GitLens docs
`gitlens.views.pageItemLimit`	Specifies the number of items to show in a each page when paginating a view list. Use 0 to specify no limit
`gitlens.views.showRelativeDateMarkers`	Specifies whether to show relative date markers (Less than a week ago, Over a week ago, Over a month ago, etc) on revision (commit) histories in the views

Commits View Settings

See also View Settings

Name	Description
`gitlens.views.commits.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Commits view
`gitlens.views.commits.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Commits view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.commits.files.layout`	Specifies how the Commits view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.commits.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Commits view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.commits.pullRequests.enabled`	Specifies whether to query for pull requests associated with the current branch and commits in the Commits view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.commits.pullRequests.showForBranches`	Specifies whether to query for pull requests associated with the current branch and commits in the Commits view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.commits.pullRequests.showForCommits`	Specifies whether to show pull requests (if any) associated with the current branch in the Commits view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.commits.reveal`	Specifies whether to reveal commits in the Commits view, otherwise they will be revealed in the Repositories view
`gitlens.views.commits.showBranchComparison`	Specifies whether to show a comparison of the current branch or the working tree with a user-selected reference (branch, tag. etc) in the Commits view `false` – hides the branch comparison `branch` – compares the current branch with a user-selected reference `working` – compares the working tree with a user-selected reference

Repositories View Settings

See also View Settings

Name	Description
`gitlens.views.repositories.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Repositories view
`gitlens.views.repositories.autoRefresh`	Specifies whether to automatically refresh the Repositories view when the repository or the file system changes
`gitlens.views.repositories.autoReveal`	Specifies whether to automatically reveal repositories in the Repositories view when opening files
`gitlens.views.repositories.branches.layout`	Specifies how the Repositories view will display branches `list` – displays branches as a list `tree` – displays branches as a tree when branch names contain slashes `/`
`gitlens.views.repositories.branches.showBranchComparison`	Specifies whether to show a comparison of the branch with a user-selected reference (branch, tag. etc) under each branch in the Repositories view view
`gitlens.views.repositories.compact`	Specifies whether to show the Repositories view in a compact display density
`gitlens.views.repositories.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Repositories view. Only applies when `gitlens.views.repositories.files.layout` is set to `tree` or `auto`
`gitlens.views.repositories.files.layout`	Specifies how the Repositories view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.repositories.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.repositories.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Repositories view. Only applies when `gitlens.views.repositories.files.layout` is set to `auto`
`gitlens.views.repositories.includeWorkingTree`	Specifies whether to include working tree file status for each repository in the Repositories view
`gitlens.views.repositories.showBranchComparison`	Specifies whether to show a comparison of a user-selected reference (branch, tag. etc) to the current branch or the working tree in the Repositories view
`gitlens.views.repositories.showBranches`	Specifies whether to show the branches for each repository in the Repositories view
`itlens.views.repositories.showCommits`	Specifies whether to show the commits on the current branch for each repository in the Repositories view
`gitlens.views.repositories.showContributors`	Specifies whether to show the contributors for each repository in the Repositories view
`gitlens.views.repositories.showIncomingActivity`	Specifies whether to show the experimental incoming activity for each repository in the Repositories view
`gitlens.views.repositories.showRemotes`	Specifies whether to show the remotes for each repository in the Repositories view
`gitlens.views.repositories.showStashes`	Specifies whether to show the stashes for each repository in the Repositories view
`gitlens.views.repositories.showTags`	Specifies whether to show the tags for each repository in the Repositories view
`gitlens.views.repositories.showUpstreamStatus`	Specifies whether to show the upstream status of the current branch for each repository in the Repositories view

File History View Settings

See also View Settings

Name	Description
`gitlens.views.fileHistory.avatars`	Specifies whether to show avatar images instead of status icons in the File History view

Line History View Settings

See also View Settings

Name	Description
`gitlens.views.lineHistory.avatars`	Specifies whether to show avatar images instead of status icons in the Line History view

Branch View Settings

See also View Settings

Name	Description
`gitlens.views.branches.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Branches view
`gitlens.views.branches.branches.layout`	Specifies how the Branches view will display branches `list` – displays branches as a list `tree` – displays branches as a tree
`gitlens.views.branches.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Branches view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.branches.files.layout`	Specifies how the Branches view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.branches.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Branches view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.branches.pullRequests.enabled`	Specifies whether to query for pull requests associated with the current branch and commits in the Branches view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.branches.pullRequests.showForBranches`	Specifies whether to query for pull requests associated with the current branch and commits in the Branches view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.branches.pullRequests.showForCommits`	Specifies whether to show pull requests (if any) associated with the current branch in the Branches view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.branches.reveal`	Specifies whether to reveal branches in the Branches view, otherwise they will be revealed in the Repositories view
`gitlens.views.branches.showBranchComparison`	Specifies whether to show a comparison of the branch with a user-selected reference (branch, tag. etc) in the Branches view `false` – hides the branch comparison `branch` – compares the current branch with a user-selected reference

Remotes View Settings

See also View Settings

Name	Description
`gitlens.views.remotes.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Remotes view
`gitlens.views.remotes.branches.layout`	Specifies how the Remotes view will display branches `list` – displays branches as a list `tree` – displays branches as a tree
`gitlens.views.remotes.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Remotes view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.remotes.files.layout`	Specifies how the Remotes view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.remotes.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Remotes view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.remotes.pullRequests.enabled`	Specifies whether to query for pull requests associated with the current branch and commits in the Remotes view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.remotes.pullRequests.showForBranches`	Specifies whether to query for pull requests associated with the current branch and commits in the Remotes view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.remotes.pullRequests.showForCommits`	Specifies whether to show pull requests (if any) associated with the current branch in the Remotes view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.remotes.reveal`	Specifies whether to reveal remotes in the Remotes view, otherwise they will be revealed in the Repositories view
`gitlens.views.remotes.showBranchComparison`	Specifies whether to show a comparison of the branch with a user-selected reference (branch, tag. etc) in the Remotes view `false` – hides the branch comparison `branch` – compares the current branch with a user-selected reference

Stashes View Settings

See also View Settings

Name	Description
`gitlens.views.stashes.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Stashes view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.stashes.files.layout`	Specifies how the Stashes view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.stashes.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Stashes view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.stashes.reveal`	Specifies whether to reveal stashes in the Stashes view, otherwise they will be revealed in the Repositories view

Tags View Settings

See also View Settings

Name	Description
`gitlens.views.tags.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Tags view
`gitlens.views.tags.branches.layout`	Specifies how the Tags view will display tags `list` – displays tags as a list `tree` – displays tags as a tree
`gitlens.views.tags.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Tags view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.tags.files.layout`	Specifies how the Tags view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.tags.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Tags view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.tags.reveal`	Specifies whether to reveal tags in the Tags view, otherwise they will be revealed in the Repositories view

Contributors View Settings

See also View Settings

Name	Description
`gitlens.views.contributors.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Contributors view
`gitlens.views.contributors.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Contributors view. Only applies when `gitlens.views.commits.files.layout` is set to `tree` or `auto`
`gitlens.views.contributors.files.layout`	Specifies how the Contributors view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.commits.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.contributors.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Contributors view Only applies when `gitlens.views.commits.files.layout` is set to `auto`
`gitlens.views.contributors.pullRequests.enabled`	Specifies whether to query for pull requests associated with the current branch and commits in the Contributors view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.contributors.pullRequests.showForCommits`	Specifies whether to show pull requests (if any) associated with the current branch in the Contributors view. Requires a connection to a supported remote service (e.g. GitHub)
`gitlens.views.contributors.showAllBranches`	Specifies whether to show commits from all branches in the Contributors view
`gitlens.views.contributors.showStatistics`	Specifies whether to show contributor statistics in the Contributors view. This can take a while to compute depending on the repository size

Search & Compare View Settings

See also View Settings

Name	Description
`gitlens.views.compare.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Search Commits view Only applies when `gitlens.views.compare.files.layout` is set to `auto`
`gitlens.views.compare.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Compare view
`gitlens.views.compare.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Compare view. Only applies when `gitlens.views.compare.files.layout` is set to `tree` or `auto`
`gitlens.views.compare.files.layout`	Specifies how the Compare view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.compare.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree
`gitlens.views.compare.files.threshold`	Specifies when to switch between displaying files as a `tree` or `list` based on the number of files in a nesting level in the Compare view. Only applies when `gitlens.views.compare.files.layout` is set to `auto`
`gitlens.views.search.avatars`	Specifies whether to show avatar images instead of commit (or status) icons in the Search Commits view
`gitlens.views.search.files.compact`	Specifies whether to compact (flatten) unnecessary file nesting in the Search Commits view Only applies when `gitlens.views.compare.files.layout` is set to `tree` or `auto`
`gitlens.views.search.files.layout`	Specifies how the Search Commits view will display files `auto` – automatically switches between displaying files as a `tree` or `list` based on the `gitlens.views.compare.files.threshold` value and the number of files at each nesting level `list` – displays files as a list `tree` – displays files as a tree

Gutter Blame Settings

Name	Description
`gitlens.blame.avatars`	Specifies whether to show avatar images in the gutter blame annotations
`gitlens.blame.compact`	Specifies whether to compact (deduplicate) matching adjacent gutter blame annotations
`gitlens.blame.dateFormat`	Specifies how to format absolute dates (e.g. using the `${date}` token) in gutter blame annotations. See the Moment.js docs for valid formats
`gitlens.blame.format`	Specifies the format of the gutter blame annotations. See Commit Tokens in the GitLens docs. Date formatting is controlled by the `gitlens.blame.dateFormat` setting
`gitlens.blame.heatmap.enabled`	Specifies whether to provide a heatmap indicator in the gutter blame annotations
`gitlens.blame.heatmap.location`	Specifies where the heatmap indicators will be shown in the gutter blame annotations `left` – adds a heatmap indicator on the left edge of the gutter blame annotations `right` – adds a heatmap indicator on the right edge of the gutter blame annotations
`gitlens.blame.highlight.enabled`	Specifies whether to highlight lines associated with the current line
`gitlens.blame.highlight.locations`	Specifies where the associated line highlights will be shown `gutter` – adds a gutter indicator `line` – adds a full-line highlight background color `overview` – adds a decoration to the overview ruler (scroll bar)
`gitlens.blame.ignoreWhitespace`	Specifies whether to ignore whitespace when comparing revisions during blame operations
`gitlens.blame.separateLines`	Specifies whether gutter blame annotations will have line separators
`gitlens.blame.toggleMode`	Specifies how the gutter blame annotations will be toggled `file` – toggles each file individually `window` – toggles the window, i.e. all files at once

Gutter Changes Settings

Name Description

Name	Description
`gitlens.changes.locations`	Specifies where the indicators of the gutter changes annotations will be shown `gutter` – adds a gutter indicator `overview` – adds a decoration to the overview ruler (scroll bar)
`gitlens.changes.toggleMode`	Specifies how the gutter changes annotations will be toggled `file` – toggles each file individually `window` – toggles the window, i.e. all files at once

gitlens.changes.locations

Specifies where the indicators of the gutter changes annotations will be shown

gutter – adds a gutter indicator
overview – adds a decoration to the overview ruler (scroll bar)

gitlens.changes.toggleMode

Specifies how the gutter changes annotations will be toggled

file – toggles each file individually
window – toggles the window, i.e. all files at once

Gutter Heatmap Settings

Name	Description
`gitlens.heatmap.ageThreshold`	Specifies the age of the most recent change (in days) after which the gutter heatmap annotations will be cold rather than hot (i.e. will use `gitlens.heatmap.coldColor` instead of `gitlens.heatmap.hotColor`)
`gitlens.heatmap.coldColor`	Specifies the base color of the gutter heatmap annotations when the most recent change is older (cold) than the `gitlens.heatmap.ageThreshold` value
`gitlens.heatmap.hotColor`	Specifies the base color of the gutter heatmap annotations when the most recent change is newer (hot) than the `gitlens.heatmap.ageThreshold` value
`gitlens.heatmap.locations`	Specifies where the indicators of the gutter heatmap annotations will be shown `gutter` – adds a gutter indicator `overview` – adds a decoration to the overview ruler (scroll bar)
`gitlens.heatmap.toggleMode`	Specifies how the gutter heatmap annotations will be toggled `file` – toggles each file individually `window` – toggles the window, i.e. all files at once

Git Command Palette Settings

Name	Description
`gitlens.gitCommands.closeOnFocusOut`	Specifies whether to dismiss the Git Commands Palette when focus is lost (if not, press `ESC` to dismiss)
`gitlens.gitCommands.search.matchAll`	Specifies whether to match all or any commit message search patterns
`gitlens.gitCommands.search.matchCase`	Specifies whether to match commit search patterns with or without regard to casing
`gitlens.gitCommands.search.matchRegex`	Specifies whether to match commit search patterns using regular expressions
`gitlens.gitCommands.search.showResultsInSideBar`	Specifies whether to show the commit search results directly in the quick pick menu, in the Side Bar, or will be based on the context
`gitlens.gitCommands.skipConfirmations`	Specifies which (and when) Git commands will skip the confirmation step, using the format: `git-command-name:(menu/command)`
`gitlens.gitCommands.sortBy`	Specifies how Git commands are sorted in the Git Command Palette `name` – sorts commands by name `usage` – sorts commands by last used date

Terminal Links Settings

Name	Description
`gitlens.terminalLinks.enabled`	Specifies whether to enable terminal links — autolinks in the integrated terminal to quickly jump to more details for commits, branches, tags, and more

Remote Provider Integration Settings

Name Description

gitlens.integrations.enabled Specifies whether to enable rich integrations with any supported remote services

Name	Description
`gitlens.integrations.enabled`	Specifies whether to enable rich integrations with any supported remote services
`gitlens.remotes`	Specifies custom remote services to be matched with Git remotes to detect custom domains for built-in remote services or provide support for custom remote services Supported Types (e.g. `"type": "GitHub"`): “GitHub” “GitLab” “Gerrit” “Gitea” “AzureDevOps” “Bitbucket” “BitbucketServer” “Custom” Example: `"gitlens.remotes": [{ "domain": "git.corporate-url.com", "type": "GitHub" }]` Example: `"gitlens.remotes": [{ "regex": "ssh://(my.company.com):1234/git/(.+)", "type": "GitHub" }]` Example: `"gitlens.remotes": [{` `"domain": "git.corporate-url.com",` `"type": "Custom",` `"name": "My Company",` `"protocol": "https",` `"urls": {` `"repository": "https://git.corporate-url.com/${repo}",` `"branches": "https://git.corporate-url.com/${repo}/branches",` `"branch": "https://git.corporate-url.com/${repo}/commits/${branch}",` `"commit": "https://git.corporate-url.com/${repo}/commit/${id}",` `"file": "https://git.corporate-url.com/${repo}?path=${file}${line}",` `"fileInBranch": "https://git.corporate-url.com/${repo}/blob/${branch}/${file}${line}",` `"fileInCommit": "https://git.corporate-url.com/${repo}/blob/${id}/${file}${line}",` `"fileLine": "#L${line}",` `"fileRange": "#L${start}-L${end}"` `}` `}]` Example: `"gitlens.remotes": [{` `"regex": "ssh:\/\/(my\.company\.com):1234\/git\/(.+)",` `"type": "Custom",` `"name": "My Company",` `"protocol": "https",` `"urls": {` `"repository": "https://my.company.com/projects/${repoBase}/repos/${repoPath}",` `"branches": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/branches",` `"branch": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/commits/${branch}",` `"commit": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/commit/${id}",` `"file": "https://my.company.com/projects/${repoBase}/repos/${repoPath}?path=${file}${line}",` `"fileInBranch": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/blob/${branch}/${file}${line}",` `"fileInCommit": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/blob/${id}/${file}${line}",` `"fileLine": "#L${line}",` `"fileRange": "#L${start}-L${end}"` `}` `}]`

gitlens.remotes

Specifies custom remote services to be matched with Git remotes to detect custom domains for built-in remote services or provide support for custom remote services

Supported Types (e.g. "type": "GitHub"):

“GitHub”
“GitLab”
“Gerrit”
“Gitea”
“AzureDevOps”
“Bitbucket”
“BitbucketServer”
“Custom”

Example:
"gitlens.remotes": [{ "domain": "git.corporate-url.com", "type": "GitHub" }]

Example:
"gitlens.remotes": [{ "regex": "ssh://(my.company.com):1234/git/(.+)", "type": "GitHub" }]

Example:
"gitlens.remotes": [{
"domain": "git.corporate-url.com",
"type": "Custom",
"name": "My Company",
"protocol": "https",
"urls": {
"repository": "https://git.corporate-url.com/${repo}",
"branches": "https://git.corporate-url.com/${repo}/branches",
"branch": "https://git.corporate-url.com/${repo}/commits/${branch}",
"commit": "https://git.corporate-url.com/${repo}/commit/${id}",
"file": "https://git.corporate-url.com/${repo}?path=${file}${line}",
"fileInBranch": "https://git.corporate-url.com/${repo}/blob/${branch}/${file}${line}",
"fileInCommit": "https://git.corporate-url.com/${repo}/blob/${id}/${file}${line}",
"fileLine": "#L${line}",
"fileRange": "#L${start}-L${end}"
}
}]

Example:
"gitlens.remotes": [{
"regex": "ssh:\/\/(my\.company\.com):1234\/git\/(.+)",
"type": "Custom",
"name": "My Company",
"protocol": "https",
"urls": {
"repository": "https://my.company.com/projects/${repoBase}/repos/${repoPath}",
"branches": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/branches",
"branch": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/commits/${branch}",
"commit": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/commit/${id}",
"file": "https://my.company.com/projects/${repoBase}/repos/${repoPath}?path=${file}${line}",
"fileInBranch": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/blob/${branch}/${file}${line}",
"fileInCommit": "https://my.company.com/projects/${repoBase}/repos/${repoPath}/blob/${id}/${file}${line}",
"fileLine": "#L${line}",
"fileRange": "#L${start}-L${end}"
}
}]

Date & Time Settings

Name	Description
`gitlens.defaultDateFormat`	Specifies how absolute dates will be formatted by default. See the Moment.js docs for valid formats
`gitlens.defaultDateShortFormat`	Specifies how short absolute dates will be formatted by default. See the Moment.js docs for valid formats
`gitlens.defaultDateSource`	Specifies whether commit dates should use the authored or committed date
`gitlens.defaultDateStyle`	Specifies how dates will be displayed by default
`gitlens.defaultTimeFormat`	Specifies how times will be formatted by default. See the Moment.js docs for valid formats

Menu & Toolbar Settings

Name	Description
`gitlens.menus`	Specifies which commands will be added to which menus
`gitlens.fileAnnotations.command`	Specifies whether the file annotations button in the editor title shows a menu or immediately toggles the specified file annotations `null` (default) – shows a menu to choose which file annotations to toggle `blame` – toggles gutter blame annotations `heatmap` – toggles gutter heatmap annotations `changes` – toggles gutter changes annotations

Keyboard Shortcut Settings

Name Description

Name	Description
`gitlens.keymap`	Specifies the keymap to use for GitLens shortcut keys `alternate` – adds an alternate set of shortcut keys that start with `Alt` (⌥ on macOS) `chorded` – adds a chorded set of shortcut keys that start with `Ctrl+Shift+G` (`⌥⌘G` on macOS) `none` – no shortcut keys will be added

gitlens.keymap

Specifies the keymap to use for GitLens shortcut keys

alternate – adds an alternate set of shortcut keys that start with Alt (⌥ on macOS)
chorded – adds a chorded set of shortcut keys that start with Ctrl+Shift+G (⌥⌘G on macOS)
none – no shortcut keys will be added

Modes Settings

Name	Description
`gitlens.mode.active`	Specifies the active GitLens mode, if any
`gitlens.mode.statusBar.enabled`	Specifies whether to provide the active GitLens mode in the status bar
`gitlens.mode.statusBar.alignment`	Specifies the active GitLens mode alignment in the status bar `left` – aligns to the left `right` – aligns to the right
`gitlens.modes`	Specifies the user-defined GitLens modes Example — adds heatmap annotations to the Reviewing mode `"gitlens.modes": { "review": { "annotations": "heatmap" } }` Example — adds a new Annotating mode with blame annotations `"gitlens.modes": {` `"annotate": {` `"name": "Annotating",` `"statusBarItemName": "Annotating",` `"description": "for root cause analysis",` `"annotations": "blame",` `"codeLens": false,` `"currentLine": false,` `"hovers": true` `}` `}`

Autolink Settings

Name Description

Name	Description
`gitlens.autolinks`	Specifies autolinks to external resources in commit messages. Use `<num>` as the variable for the reference number Example to autolink Jira issues: (e.g. `JIRA-123 ⟶ https://jira.company.com/issue?query=123`) `"gitlens.autolinks": [{ "prefix": "JIRA-", "url": "https://jira.company.com/issue?query=<num>" }]`

gitlens.autolinks

Specifies autolinks to external resources in commit messages. Use <num> as the variable for the reference number

Example to autolink Jira issues: (e.g. JIRA-123 ⟶ https://jira.company.com/issue?query=123)
"gitlens.autolinks": [{ "prefix": "JIRA-", "url": "https://jira.company.com/issue?query=<num>" }]

Misc Settings

Name	Description
`gitlens.defaultGravatarsStyle`	Specifies the style of the gravatar default (fallback) images `identicon` – a geometric pattern `mp` – a simple, cartoon-style silhouetted outline of a person (does not vary by email hash) `monsterid` – a monster with different colors, faces, etc `retro` – 8-bit arcade-style pixelated faces `robohash` – a robot with different colors, faces, etc `wavatar` – a face with differing features and backgrounds
`gitlens.liveshare.allowGuestAccess`	Specifies whether to allow guest access to GitLens features when using Visual Studio Live Share
`gitlens.outputLevel`	Specifies how much (if any) output will be sent to the GitLens output channel
`gitlens.showWelcomeOnInstall`	Specifies whether to show the Welcome (Quick Setup) experience on first install
`gitlens.showWhatsNewAfterUpgrades`	Specifies whether to show the What’s New notification after upgrading to new feature releases
`gitlens.sortBranchesBy`	Specifies how branches are sorted in quick pick menus and views
`gitlens.sortContributorsBy`	Specifies how contributors are sorted in quick pick menus and views
`gitlens.sortTagsBy`	Specifies how tags are sorted in quick pick menus and views
`gitlens.advanced.abbreviatedShaLength`	Specifies the length of abbreviated commit SHAs (shas)
`gitlens.advanced.abbreviateShaOnCopy`	Specifies whether to copy full or abbreviated commit SHAs to the clipboard. Abbreviates to the length of `gitlens.advanced.abbreviatedShaLength`..
`gitlens.advanced.blame.customArguments`	Specifies additional arguments to pass to the `git blame` command
`gitlens.advanced.blame.delayAfterEdit`	Specifies the time (in milliseconds) to wait before re-blaming an unsaved document after an edit. Use 0 to specify an infinite wait
`gitlens.advanced.blame.sizeThresholdAfterEdit`	Specifies the maximum document size (in lines) allowed to be re-blamed after an edit while still unsaved. Use 0 to specify no maximum
`gitlens.advanced.caching.enabled`	Specifies whether git output will be cached — changing the default is not recommended
`gitlens.advanced.commitOrdering`	Specifies the order by which commits will be shown. If unspecified, commits will be shown in reverse chronological order `date` – shows commits in reverse chronological order of the commit timestamp `author-date` – shows commits in reverse chronological order of the author timestamp `topo` – shows commits in reverse chronological order of the commit timestamp, but avoids intermixing multiple lines of history
`gitlens.advanced.externalDiffTool`	Specifies an optional external diff tool to use when comparing files. Must be a configured Git difftool.
`gitlens.advanced.externalDirectoryDiffTool`	Specifies an optional external diff tool to use when comparing directories. Must be a configured Git difftool.
`gitlens.advanced.fileHistoryFollowsRenames`	Specifies whether file histories will follow renames — will affect how merge commits are shown in histories
`gitlens.advanced.fileHistoryShowAllBranches`	Specifies whether file histories will show commits from all branches
`gitlens.advanced.maxListItems`	Specifies the maximum number of items to show in a list. Use 0 to specify no maximum
`gitlens.advanced.maxSearchItems`	Specifies the maximum number of items to show in a search. Use 0 to specify no maximum
`gitlens.advanced.messages`	Specifies which messages should be suppressed
`gitlens.advanced.quickPick.closeOnFocusOut`	Specifies whether to dismiss quick pick menus when focus is lost (if not, press `ESC` to dismiss)
`gitlens.advanced.repositorySearchDepth`	Specifies how many folders deep to search for repositories
`gitlens.advanced.similarityThreshold`	Specifies the amount (percent) of similarity a deleted and added file pair must have to be considered a rename
`gitlens.strings.codeLens.unsavedChanges.recentChangeAndAuthors`	Specifies the string to be shown in place of both the recent change and authors CodeLens when there are unsaved changes
`gitlens.strings.codeLens.unsavedChanges.recentChangeOnly`	Specifies the string to be shown in place of the recent change CodeLens when there are unsaved changes
`gitlens.strings.codeLens.unsavedChanges.authorsOnly`	Specifies the string to be shown in place of the authors CodeLens when there are unsaved changes

Themable Colors

GitLens defines a set of themable colors which can be provided by vscode themes or directly by the user using workbench.colorCustomizations.

Name	Description
`gitlens.gutterBackgroundColor`	Specifies the background color of the gutter blame annotations
`gitlens.gutterForegroundColor`	Specifies the foreground color of the gutter blame annotations
`gitlens.gutterUncommittedForegroundColor`	Specifies the foreground color of an uncommitted line in the gutter blame annotations
`gitlens.trailingLineBackgroundColor`	Specifies the background color of the trailing blame annotation
`gitlens.trailingLineForegroundColor`	Specifies the foreground color of the trailing blame annotation
`gitlens.lineHighlightBackgroundColor`	Specifies the background color of the associated line highlights in blame annotations
`gitlens.lineHighlightOverviewRulerColor`	Specifies the overview ruler color of the associated line highlights in blame annotations

Have feedback about this article? Did we miss something? Let us know!

GitLens Settings

GitLens Settings

Current Line Blame Settings

Git CodeLens Settings

Status Bar Settings

Hover Settings

View Settings

Commits View Settings

Repositories View Settings

File History View Settings

Line History View Settings

Branch View Settings

Remotes View Settings

Stashes View Settings

Tags View Settings

Contributors View Settings

Search & Compare View Settings

Gutter Blame Settings

Gutter Changes Settings

Gutter Heatmap Settings

Git Command Palette Settings

Terminal Links Settings

Remote Provider Integration Settings

Date & Time Settings

Menu & Toolbar Settings

Keyboard Shortcut Settings

Modes Settings

Autolink Settings

Misc Settings

Themable Colors

On this page
